Stainless steel rod, zamak, support. 90° limited opening load: WEEN HIDE 110: 150 kg combined with 3311.XX/3312.XX, 140 kg combined with 3313.XX WEEN HIDE 180: 180 kg combined with 3303A.XX/3304A.XX, 150 kg combined with 3305.XX/3306.XX
Extended hinge suitable for use on external opening shutters and window frames. 2-flap hinge length 27 mm Capacity: With 2 hinges: 40 Kg With 3 hinges: 50 Kg
Extended hinge suitable for use on external opening shutters and window frames. Hinge length 38 mm. Capacity: With 2 hinges: 40 Kg With 3 hinges: 50 Kg
extruded aluminium flaps; nylon bushing and caps; pin, plates and locking screws M5 TSC CR in stainless steel. 27 mm long hinge. Capacity: With 2 hinges: 40 Kg With 3 hinges: 50 Kg
Extruded aluminium flaps; nylon bushing; pin, plates and screws in stainless steel. 40 mm long hinge. Capacity: With 2 hinges: 40 Kg With 3 hinges: 50 Kg
Extended hinge suitable for use on external opening shutters and window frames. Hinge length 43 mm. Capacity: With 2 hinges: 40 Kg With 3 hinges: 50 Kg
